Cat 6 RJ45 Modular Plug is a common connector used in network cabling, usually used to enable connections and changes between devices, patch panel modules.
The Cat 6 RJ45 Modular Plug has 8 contacts, or 8P.
Its components include a crystal head, internal pair termination locator, internal pair separation locator, sheath locker, and skinny tail sheath.
Modular plugs
1) All modular plugs RJ11 RJ12 RJ45 connectors are available:
8P8C, 8P4C, 6P4C, 6P2C, 4P4C, 4P2C; RJ11/RJ12/RJ45/RJ48 connector, UTP/FTP/STP/SFTP/SSTP, color modular plugs, or UK plugs are all
available.
2) Gold plating thickness: gold flash, FU,01,03, 06, 15, 30, 50U”.
3) UL/RoHS compliant.
4) Imported materials:
Imported polycarbonate material with good transparency and flexibility.
5) Designed according to FCC standard, and fully compatible with different jacks.
6) Standard packing: 1000pcs or 100pcs/bag with a sticker to mark specification.
For round cable, featuring gold plated contacts for the best possible connection. Manufactured from a leader in the network cables industry, Make your network function to it's maximum potential.
Product Parameter
Color | Low quality connector : connector color is not translucence | ||
Working time | Low quality Connector : the times of plugging and unplugging is short . Around 400 times will be broken . | ||
Working time | "U" is about the thickness of the Gold plating. The connector signal transmission quality based on the thickness of Gold | ||
Name | Cat.6 Toolless plug | Texture | ABS Plastic |
Color | Red(cat6) Yellow(cat5e) | Pack | In Bag |
Apply | Wiring,home School | Weight | 6.8g/pcs |
Performance & Features:
Contacts are plated with 50 micro inches of gold to provide superior electrical performance and oxidation resistance with a plug durability typically greater than or equal to 750 cycles.
Designed with angled tangle-free locking pins, which help prevent tangling with other cables, making plugging and unplugging easier and saving time.
Built-in pair separation manager helps reduce pair untwisting for enhanced electrical performance.
Supports specific wire gauges, such as 24AWG, as well as single or stranded conductors, with a maximum acceptable wire insulation diameter of typically 0.041 inches.
Range of Applications:
The Cat 6 RJ45 Modular Plug is designed to support Gigabit and higher speed Ethernet and can transfer data at speeds up to 10GbpsIt is suitable for application scenarios that require high-performance network connectivity, such as data centres, server rooms, multimedia streaming and high-bandwidth applications.
This connector is also widely used in a variety of environments and industries such as office networks, educational institutions, healthcare facilities and residential settings.
The Cat 6 RJ45 Modular Plug is a high-performance, high-durability network connector for a variety of scenarios that require high-speed, stable network connectivity.
|
|
* 50 pcs Rj45 plugs for unshielded twisted pair solid or stranded cable, supports 24 to 26 AWG round or flat network cable
* Gold-plated contacts provide reliable performance for a Gigabit Ethernet rated network
* CAT5/5e Cable easily passes through connector to visually ensure that wires are in the correct order for consistent and secure terminations
* 8 position, 8 contact Pass Through style data plug for solid or stranded cable
* Easy to use, even if it’s your first time
Fangbei, a premier manufacturer specializing in network connectors, terminals, electronic components, and cutting-edge network tools.
